安訊士AXIS F1025 Sensor Unit 銀行柜員機專用針孔監控網絡攝像頭單元
Pinhole lens and HDTV resolution for extremely discreet indoor surveillance
- Flexible, extremely discreet design for indoor use
- Pinhole lens with 1080p resolution
- Wide 92° horizontal field of view
- Supports WDR – Forensic Capture (with AXIS F41/F44 Main Unit)
Extremely discreet installation
AXIS F1025 Sensor Unit, together with an AXIS F Main Unit, is ideal for use in extremely discreet indoor surveillance applications, such as in ATMs (automated teller machines), banks, stores, hotels and elevators. The small AXIS F1025 unit can be installed, for instance, in tight places, in doorways, behind metal sheets or flush-mounted in a wall or ceiling, with only a pin hole visible for the lens.
AXIS F1025 comprises an image sensor with 1080p resolution (1920 x 1080 pixels) and a pinhole lens that provides a wide 92° horizontal field of view.
AXIS F1025 also supports Wide Dynamic Range (WDR) – Forensic Capture, which can be activated when the sensor unit is connected to a main unit that supports this feature. WDR – Forensic Capture enables a high level of detail to be visible in both the bright and dark areas of a scene.
AXIS F1025 comes with a 3-m or 12-m (10 ft. or 39 ft.) pre-mounted cable for connection to an AXIS F Main Unit. An AXIS F8202 Straight Mounting Bracket is included for mounting on a flat surface.
At left, image without WDR – Forensic Capture, where only details in the bright areas are visible. At right, image from AXIS F1025 Sensor Unit and AXIS F41 Main Unit with WDR – Forensic Capture, where details in both bright and dark areas are visible.
AXIS F41 Main Unit and AXIS F1025 Sensor Unit
See the difference Axis' Wide Dynamic Range - Forensic Capture makes in a scene with backlight.
