Bosch Bosch nbe-4502-al bullet 2MP HDR 2.8-12mm, automatic, IP67 ik10 webcam
Business type: nbe-4502-al
Product No.: f.01u three hundred and twenty-eight point two one two
Installation is easier with features such as auto zoom / focus lens, setup wizard and preconfigured mode
The built-in infrared lamp can view objects at a distance of 60 meters (196 feet)
1080p30 high definition images available
Built in essential video analytics for triggering related alerts and quickly retrieving data
Multiple fully configurable h.265 data streams
Power Supply
Input voltage Ethernet power supply (rated 48 VDC); Or 24 VAC ± 10% / + 12 VDC ± 10%
Poe IEEE standard IEEE 802.3af (802.3at type 1) power level: Class 3
Power consumption 950 MA (12 VDC) 750 MA (24 VAC) 260 MA (POE)
Sensor
Sensor type 1 / 2.8 inch CMOS
Effective picture pixel 1937 (horizontal) x 1097 (vertical); Approx. 2.12 mp
Video performance - sensitivity
Sensitivity – (3200K, reflectivity 89%, f1.4, 30ire)
Color 0.052 Lux
Black and white 0.008 Lux
Including infrared lamp 0.0 LX
Dynamic range 85 dB wide dynamic range (WDR) according to IEC 62676 Part 5
Video stream
Video compression h.265; H.264； M- JPEG
Data stream multiple configurable H.264 or h.265 and M-JPEG data streams, configurable frame rate and bandwidth. Region of interest (ROI)
Camera processing delay < 55 ms (maximum average at 1080p30) < 65 ms (maximum average at 5mp30)
GOP structure IP, IBP, ibbp
Coding interval 1 to 25 [30] FPS
There are up to 8 coding areas, and each area has encoder quality settings
Video definition (horizontal x vertical)
1080p HD 1920 x 1080
Vertical mode 1080p 1080 x 1920
1.3 MP (5:4) (cut) 1280 x 1024
Vertical mode 1.3 MP (5:4) (crop) 1024 x 1280
720p HD 1280 x 720
Vertical mode 720p 720 x 1280
D1 4:3 (cut) 704 x 480
432p SD 768 x 432
288p SD 512 x 288
144p SD 256 x 144
Camera installation
Basic frame rate 25 / 30 FPS (PAL / NTSC analog output)
Camera led enable / disable
Analog output off, 4:3 mailbox, 4:3 clipping, 16:9
Positioning coordinates / installation
Lens wizard, zoom, auto focus
Video function - color
Adjustable image settings: contrast, saturation and brightness
White balance 2500 to 10000K, 4 automatic modes (basic, standard, sodium light, main color), manual mode and hold mode
Video function - ALC
Day / night automatic (adjustable), color, black and white
Shutter automatic electronic shutter (AES); Optional fixed shutter (1 / 25 [30] to 1 / 15000); Default shutter
Adjustable infrared intensity
Video features - enhanced
Sharpness you can choose the sharpness enhancement level
Backlight compensation on / off
Contrast enhancement on / off
Intelligent dynamic noise reduction with independent adjustment of time and space
Intelligent defog automatically adjusts parameters to get the best picture in foggy or blurred scenes (switchable)
Signal to noise ratio (SNR) > 55dB
Video content analysis
Analysis type essential video analytics
Feature rule based alarm and tracking cross line entry / exit site follow path wandering target left / removed personnel count crowd density estimation 3D tracking
Other functions
Scene mode 9 default modes, schedule
Privacy masking 8 independent areas, fully programmable
Video verification off / watermark / MD5 / SHA-1 / SHA-256
Display tag name; Logo; Time; Alarm information
Pixel counter optional area
