WV-SFN533LH



Enhanced super dynamic full HD infrared network hemispherical camera



◆ Full HD / 1920x1080 60fps H.264 enhanced super dynamic infrared network hemispherical camera




1080p Full HD real-time image up to 60fps * 1.

About 1 / 2.8 inch, high sensitivity MOS sensor.

High sensitivity MOS sensor creates Full HD 1920x1080 ultra-high resolution image.

H. 264 (high profile) (up to 4 streams) and JPEG multi stream output through Panasonic's new enhanced patented system chip "uniphier" ? ", realize real-time monitoring and HD video recording synchronously.

In 16:9 mode, the sub code stream can also be selected 800x600@30fps *June 2015.

The maximum image size is 2048x1536 * @ 30fps, H.264.

*Using super resolution technology

Compared with traditional cameras, enhanced super dynamic technology * 1 and ABS (automatic dark area compensation) technology can achieve 133dB wide dynamic range shooting.

MNR (multiprocessing noise reduction technology) & 3d-dnr can reduce noise in a variety of environments.

High sensitivity day night conversion function (infrared filter color to black):

F1. At 7 o'clock, it is 0.07lux in color mode; 0.01LUX in black and white mode.

Built in infrared LED light: infrared LED light enables the camera to shoot at 0Lux at night.

The output power of the infrared LED lamp can be automatically controlled according to the surrounding environment, so that the camera can clearly capture the face image without overexposure.

AF (auto focus) makes installation easy.

RS485 interface, which can conduct two-way communication with cash counter, access control and other RS485 equipment.

AC 24V / POE dual power interface to adapt to complex and diverse power environment.

Viqs (adjustable image quality of designated area) technology allows the designated eight areas to retain high-quality images, while the image quality of non designated areas is low. Smaller bitstreams can be used to transmit files.

The screen clipping function can provide both overall image and local image. Up to 4 image capture areas can be specified, and their order can be controlled.

Super dynamic facial technology ensures clear facial images.

256 level adjustment can compensate and correct the deformed image.

Electronic sensitivity improvement: automatic (up to 16 / 30 seconds) / off.

Optional light quantity control mode:

Outdoor, indoor (50Hz) / indoor (60Hz), fixed shutter

Indoor (50Hz / 60Hz): it can automatically compensate the flashing of fluorescent lamps.

3x extra optical zoom at 640X360 resolution.

2x and 4x electronic zoom under browser control.

VMD (video movement detection) has 4 areas, 15 levels of sensitivity and 10 levels of detection size.

The privacy area can cover 8 areas such as windows and entrances and exits.

Camera caption display: the browser can display up to 20 characters.

The alarm source includes three terminal input, VMD and Panasonic alarm instructions. These alarm sources can trigger SDXC / SDHC / SD memory card recording, FTP image transmission, email notification and browsing

Display, alarm terminal output and Panasonic protocol output.

Full duplex bidirectional audio can support the interactive communication between the front-end camera and the back-end monitoring platform.

The JPEG image compression ratio can be changed due to the alarm signal to provide a higher quality image.

Priority stream control: when multiple video recorders or client computers access the camera at the same time, one video stream can be set as priority, so as to ensure that the video recorder or client computer maintains a stable frame rate.

SDXC / SDHC / SD memory card slot can be used for manual recording (H.264 / JPEG), alarm recording (H.264 / JPEG) and recording in case of network failure (H.264 / JPEG). Realize long-term recording and automatic backup.

The newly developed spherical cover can provide clearer images above the horizontal, thus expanding the tilt range of the lens.

The face detection function can detect the face position and send information through XML or video stream. (optional wv-sae100 or wv-sae200)

In addition to the built-in VMD (video movement detection) and alarm functions, new intelligent extension software can also be added. (optional wv-sae200)

Fog penetration compensation function.

HLC (strong light suppression technology): if a strong light source (such as car headlights) shines in the direction of the camera, the camera can correct the strong light and its surrounding environment, so as to provide a clear image.

SCC (super chromaticity Compensation Technology) can better realize color restoration even under low illumination.

H. 264 maximum bit rate / client and total bit rate control function can realize flexible network communication management. The frame rate priority mode controls the bit rate and compression ratio to provide a specific frame rate.

Internet mode: H.264 images can be transmitted according to HTTP protocol.

Multilingual: Chinese / English / Italian / French / German / Spanish / Portuguese / Russian / Japanese.

Support IPv4 / IPv6 protocol.

Support DDNS (viewnetcam, rfc2136).

Still images (JPEG format) can be viewed online through mobile phones.

Comply with onvif.

*1. The super dynamic function will be automatically turned off in 60fps mode.
